RR-701 : "SEBCO" STEEL RIM WESTRIC TYPE (SIDE SEAM)
Size: 26"x 1-3/8", 24" x 1.3/8", 26 x 1½" x 1-5/8"
Number & size of holes to order for spokes
11G. 12G. 14G. 15G |
RR-702 : "SEBCO" STEEL RIM WESTRIC TYPE (CENTRE SEAM)
Size 26" x 1-3/8", 24" x 1-3/8", 26" x 1½" x 1-5/8"
Number & size of holes to order for spokes
11G.12G,14G. 15G. |
RR-703 : "SEBCO" STEEL RIMS ENDRIC TYPE (HOOK BEAD)
Size: 26"x2.125", 26"x1.75", 26"x1.95"
24"x2.125", 24"x1.75", 24"x1.95", 20"x1.75" or
2.125, 16"x1.75 or 2.125", 12"x1/2" x 1-1/4"
Number & of holes to order for spokesfor 14 gauge spokes |
RR-704 : "SEBCO" STEEL RIM WESTWOOD TYPE
Size. 28"x1-1/2", 26"x1.1/2", 24" x 1.1/2", 26"x
2" x 1.3/4", 26" x 1.1/2" x 2"
Number & size of holes to order for spokes 10G, 11G,12G, 13G, 14G, 15G
Heavy duty rims also available. |
RR-705 : "SEBCO" STEEL RIMS ENDRIC TYPE CENTRE & SIDE
NURLED
Size: 28" x 1.5/8" 26" x 1.1/4", 27" x 1.1/4", 26" x
1.1/2" x 1.5/8", 26"x1.1/2"x1.3/8". 26" x 1.3/8"
for 14guage holes |
RR-715 : "SEBCO" SPOKES
Spokes with nipples and washers manufactured from high carbon steel (EN-8) wire in
galavanised & ZP finish with brass' steel nipples.
 |
| Size
Wheel |
Length
mm |
| 28" |
305-308 |
| 27" |
300 |
| 26" |
282-285 |
| 24" |
257 |
| 20" |
197-216 |
| 16" |
170 |
| G |
15"
070" |
14
080" |
13
090" |
12
-105" |
11
-115" |
10
-125" |
| dmm |
1.8 |
2.0 |
2.3 |
2.6 |
2.9 |
3.2 |
| Dmm |
4.0 |
4.0 |
4.3 |
4.6 |
5.0 |
5.8 |
|
|
|
